MCU
Part Number: RTL8720DF 32-bit KM4 (Arm Cortex-M33 compatible) 32-bit KM0 (Arm Cortex-M23 compatible)
Memory
512KB SRAM + 4MB Flash
Key Features
Integrated WiFi 4 (802.11 b/g/n 1x1) SoC
Dual-band, 2.4GHz or 5GHz
Bluetooth LE 5.0
Bluetooth high-power mode up to 10dB
Low Power Mode
Auto Download Mode
On-board PCB antenna
Board Dimensions, 17.8×51.8 mm
Other Features
3 UART interfaces
1 I2C interface
2 SPI interfaces
12 PWM interfaces
3 ADC interfaces
1 IR interface
Max 19 GPIO
TypeC USB port
1 SDIO interface (require adaptor)
Audio Codec(require external MIC & Speaker)
USB2.0 Host Interface (require adaptor)
