Components used in Examples ​

DHT11/DHT22

Humidity and temperature sensor

HC-SR04 Ultrasonic module

Provides distance measurement function

ILI9341 TFT LCD

TFT LCD display with SPI interface

L298N H-Bridge

Motor controller module for arduino

QVGA TFT LCD

QVGA TFT LCD display module

PMS3003/5003

Air quality sensor that detects concentration of micro particulate matters

Adafruit Ultimate GPS Breakout

High-quality GPS positioning module

Logitech C170 Webcam

Logitech C170 Webcam

MPU6050

Six-Axis (Gyro + Accelerometer) MotionTracking Devices

DS1307

Low-power serial real-time clock

DS3231

Low-power serial real-time clock

Tower Pro SG90

Tiny and lightweight servo with high output power

Grove Infrared Emitter

Used to transmit infrared signals

SparkFun SX1509 I/O Expander

16-channel GPIO expander with an I2C interface

DS18B20

Digital thermometer which measures temperatures from -55°C to +125°C

RC522

RFID reader/writer IC for contactless communication

Sparkfun HTU21D

Temperature & Humidity Sensor

Dragino LoRa Shield

Long range transceiver

WS2812B RGB LED 4*4

Intelligent control LED integrated light source

Realtek ALC5680 Audio Shield

Audio Codec for powerful DSP speech processing

ALC5680

Fingerprint Scanner
